Baby Diaper Making Machine
>
High Speed Baby Diaper Manufacturing Machine PLC Control Customizable

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable

Brand Name: Womeng
Model Number: WM-FBR07
MOQ: 1
Price: $500,000.00-$800,000.00
Packaging Details: Seaworthy Wooden Box
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Detail Information
Place of Origin:
Fujian,China
Certification:
CE
Features:
High Efficiency, Stable Performance, Easy Operation
Operating Interface:
Touch Screen
Color:
Customizable
Functions:
Cutting, Folding, Sealing, Embossing, Stacking
Product Type:
Diaper Making Machine
Warranty:
1 Year
Material:
Stainless Steel
After-Sales Service:
Online Support, Field Installation, Commissioning And Training, Video Technical Support
Supply Ability:
20sets/year
Highlight:

diaper manufacturing machine plc

,

high speed diaper manufacturing machine

,

plc diaper machine manufacturing

Product Description

High Speed Big Ring Waist Baby Manufacturing Machine PLC Control with Packaging System


Product Description


Our baby diaper line is environmentally sustainable. In the selection of raw materials, priority is given to the use of degradable and renewable environmental protection materials, such as non-woven fabrics made of plant fibers and biodegradable water-absorbing core materials, to reduce the impact on the environment. In the production process, optimize the water and electricity system, introduce energy-saving equipment and water-saving technology, reduce energy consumption by 35%, and the recycling rate of water resources reaches 60%. In addition, the waste material generated in the production process is recycled and reused, and it is converted into raw materials that can be used for the production of other products through a special process to maximize the utilization of resources and practice the concept of green production.



Product Info


Product size
25m*6m*3m(for reference only)
Product structure
Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker.
Control system
PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor
Drive system
Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
Tension system
Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B
shaft active unwinding by inverter motor.
Safety system
It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
Packaging system according to customer requirements with palletizer machine (double push double exit ) adjustable
Materials corrective system
Materials corrective system: Adopt international famous brand deviation correction system
Power
380V, 50HZ three phase five wire
Machine Capacity
400KW (Excluding glue machine and air compressor)
Bleed pressure
0.6-0.8Mpa (Air compressor needs to be prepared by customers)
Machine weight 70 Tons approximately

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 0

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 1

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 2

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 3

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 4

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 5

Quanzhou Womeng Intelligent Equipment Co., Ltd. is located in Quanzhou, the cultural capital of East Asia and the starting point of the Maritime Silk Road. Founded in 2016, it is an enterprise focusing on the R&D, manufacturing and sales of paper equipment. The products cover sanitary napkin equipment, diaper equipment, pant equipment, mattress equipment, pad equipment, etc.
The company has excellent products, professional sales and technical teams, complete supporting facilities, and according to different market product specifications, each equipment is customized according to the actual needs of users, and has rich experience and technical capacity in the design and production of equipment.
Adhering to the business philosophy of honesty, cooperation and win-win, the company wholeheartedly provides high-quality products and services for new and old customers to meet the needs of customers to the greatest extent. Serving customers and achieving customers, "pioneering and innovating, pursuing excellence" is the constant pursuit of Womeng Equipment. We sincerely look forward to cooperating with new and old customers to create the future!

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 6

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 7


High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 8

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 9

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 10

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 11

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 12

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 13

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 14

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 15

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 16

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 17

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 18

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 19

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 20

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 21

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 22

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 23

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 24

High Speed Baby Diaper Manufacturing Machine PLC Control Customizable 25

Whatsapp: +008615805080212

Email:jessie@wm-machinery.com

https://www.diapersmachines.com





Employee work experience optimization


User-friendly operation interface: The design of the operation interface follows the principle of humanization, using large high-definition display and simple and easy to understand graphical operation menu. Through simple touch and click operation, employees can complete complex production parameters, such as diaper size adjustment, thickness setting of absorption core, packaging style selection. For key operation steps, set clear prompt and warning information to reduce operation errors. At the same time, the layout of the operation console conforms to the ergonomic principle, and the position and shape design of various operation buttons and handles make the operation more comfortable and convenient for employees, effectively reduce the operation fatigue of employees, and improve work efficiency. ​


Staff skills improvement and development support: The company attaches importance to the improvement of staff skills and career development, and provides rich training and learning opportunities for employees operating production lines. Organize internal training courses regularly, and explain the operation skills, maintenance points and production process optimization methods of equipment by experienced technical backbones. Encourage employees to participate in external industry training and technical seminars to broaden their knowledge and vision. For example, arrange for employees to attend 1-2 industry-renowned diaper production technology seminars every year to learn the latest technologies and concepts. In these ways, it helps employees to improve their skills, achieve career development, improve employees' job satisfaction and loyalty, and provide talent guarantee for the stable operation of the production line.


IF you want to know anything else,please contact us!
