Underpad Making Machine
>
Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine

Brand Name: Womeng
Model Number: WM-FUD18
MOQ: 1
Price: $300,000.00-$550,000.00
Packaging Details: Seaworthy Wooden Box
Payment Terms: L/C,D/A,D/P,T/T
Detail Information
Place of Origin:
Fujian,China
Certification:
CE
Conditon:
New
Machinery Test Report:
Provided
Packaging System:
Auto Stacker (Customized Design)
Working Speed:
250 Meters/min
Waste Disposal System:
Automatic Waste Disposal System
Control System:
PLC Control System
Automatic Grade:
Full Automatic
Color:
Can Be Customized
Supply Ability:
24sets/year
Highlight:

Easy Operation Underpad Production Line

,

Underpad Production Line 250 Meters/Min

,

250 Meters/Min Underpad Machine

Product Description

Production Description


This line is composed of key equipment to achieve efficient output. Raw material pretreatment equipment efficiently breaks and combs fibers. Composite equipment adopts advanced technology to quickly complete material bonding. High accuracy of molding equipment, flexible production of a variety of specifications of products. The packaging process uses automated assembly line, high-speed packaging products, the overall production process is compact, and the production efficiency is 40% higher than before.



Product Info


Product size
26m*5m*3m(for reference only)
Product structure
Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker.
Control system
PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor
Drive system
Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
Tension system
Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B
shaft active unwinding by inverter motor.
Safety system
It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
Packaging system according to customer requirements with palletizer machine (double push double exit ) adjustable
Materials corrective system
Materials corrective system: Adopt international famous brand deviation correction system
Power
380V, 50HZ three phase five wire
Machine Capacity
400KW (Excluding glue machine and air compressor)
Bleed pressure
0.6-0.8Mpa (Air compressor needs to be prepared by customers)
Machine weight 70 Tons approximately

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 0

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 1

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 2

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 3

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 4

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 5

Quanzhou Womeng Intelligent Equipment Co., Ltd. is located in Quanzhou, the cultural capital of East Asia and the starting point of the Maritime Silk Road. Founded in 2016, it is an enterprise focusing on the R&D, manufacturing and sales of paper equipment. The products cover sanitary napkin equipment, diaper equipment, pant equipment, mattress equipment, pad equipment, etc.
The company has excellent products, professional sales and technical teams, complete supporting facilities, and according to different market product specifications, each equipment is customized according to the actual needs of users, and has rich experience and technical capacity in the design and production of equipment.
Adhering to the business philosophy of honesty, cooperation and win-win, the company wholeheartedly provides high-quality products and services for new and old customers to meet the needs of customers to the greatest extent. Serving customers and achieving customers, "pioneering and innovating, pursuing excellence" is the constant pursuit of Womeng Equipment. We sincerely look forward to cooperating with new and old customers to create the future!

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 6

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 7


Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 8

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 9

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 10

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 11

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 12

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 13

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 14

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 15

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 16

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 17

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 18

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 19

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 20

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 21

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 22

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 23

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 24

Easy Operation Underpad Production Line 250 Meters/Min Underpad Machine 25

Whatsapp: +008615805080212

Email:jessie@wm-machinery.com

https://www.diapersmachines.com



The upstream and downstream industries will develop in synergy


Deep cooperation with raw material suppliers: Establish long-term and stable deep cooperation with high-quality raw material suppliers. Jointly carry out the research and development and innovation of raw materials, and develop more suitable new raw materials according to the performance requirements of care pad products. For example, cooperating with non-woven fabric suppliers to develop new non-woven fabrics with better permeability and softness; Cooperate with absorbent material supplier to improve absorbent material's absorbent ratio and water retention. At the same time, through information sharing, suppliers can timely adjust the supply arrangement according to the production plan of the production line, ensure the stable supply of raw materials, and reduce the cost of raw material inventory and supply risks of enterprises. ​


Close collaboration with downstream customers: Maintain close collaboration with downstream customers (such as medical institutions, pension institutions, distributors, etc.). In-depth understanding of customer needs and feedback, according to customer suggestions to optimize the product improvement. For example, customized production according to the special requirements of medical institutions for the size and packaging of nursing pads; According to the concern of the pension institution on the cost performance of the product, the production process is optimized to reduce the cost and ensure the product quality. Through close cooperation with downstream customers, improve customer satisfaction, enhance the market competitiveness of enterprise products, and promote the common development of enterprises and downstream industries.


IF you want to know anything else,please contact us!
